SDRplay RSP Radio Spectrum Processor

SDRplay RSP Radio Spectrum Processor
RRP: £ 119.95
£114.95 (Inc. VAT 20.00%)
Ex-VAT Price : £95.79
Add to cart
Product Information
  • Overview

KEY BENEFITS

•Ideal for portable operation •No need for an up-converter
•Covers all amateur bands from experimental LF through HF, VHF and UHF
•Simultaneous entire amateur band monitoring possible •Works with all the popular SDR software (including
HDSDR, SDR Console, Cubic SDR & our own SDRuno) •Compatible with existing open source radio software
•ExtIO based plugin available
•Compatible with Mirics Radio & TV software •Software upgradeable for future standards
•Strong and growing software support network
•API provided to allow demodulator or application development
•Multiplatform support including Windows, Linux, Mac, Android and Raspberry Pi 2/3

SPECIFICATIONS General  Weight 110g  Size: 95mm x 80mm x 30mm  Low Current: 120 – 175 mA Connectivity  Single 50Ω RF connector (SMA)  USB 2.0 (high speed) type B socket Frequency Range  Continuous coverage 10kHz – 2GHz  Frequency Tolerance: 10ppm (max) ADC Characteristics  Sample frequency 2MSPS – 10.66MSPS  12 bit native ADC  10.4 ENOB  60dB SNR  67dB SFDR IF Modes  Zero IF, All IF bandwidths  Low IF, IF bandwidths ≤ 1.536MHz IF Bandwidths (3dB)  200kHz  300kHz  600kHz  1.536MHz  5.0 MHz  6.0 MHz  7.0 MHz  8.0 MHz

Typical Noise Figures  12.5dB @ 3MHz  12.0dB @ 10MHz  11.5dB @ 20MHz  12.0dB @ 40MHz  4.5dB @ 100MHz  4.5dB @ 200MHz  5.0dB @ 360MHz  3.5dB @ 600MHz  3.5dB @ 1300MHz  4.0dB @ 1800MHz Front End Filtering Automatically configured front end filtering Low Pass 12MHz Band Pass  12 – 30MHz  30 – 60MHz  60 – 120MHz  120 – 250MHz  250 – 420MHz  420 – 1000MHz High Pass  1000MHz

Technical information
