Yaesu G-450CDC - New Version
- Home
- ACCESSORIES
- Rotators Yaesu G-450CDC - New Version
Notify Me When Available
Product Information
- Overview
- Specifications
NEW! Motor now DC and not AC.
Rotator Plugs now included worth £26.95!
PLEASE NOTE IF YOU WANT TO MOUNT THIS ROTATOR ON A POLE YOU WILL NEED THE GC-038.
Yaesu G-450 Light/Medium-Duty Rotator, perfect for entry-level requirements.
The G-450C is ideal for turning a VHF system, or a lightweight HF tribander.
Features:
Compass Display - Stop may be set at North of South.
Gear System - Quiet, gear reduction braking system
Quick Disconnect Plug - For safety during lightning
Rotator Plugs now included worth £26.95!
PLEASE NOTE IF YOU WANT TO MOUNT THIS ROTATOR ON A POLE YOU WILL NEED THE GC-038.
Yaesu G-450 Light/Medium-Duty Rotator, perfect for entry-level requirements.
The G-450C is ideal for turning a VHF system, or a lightweight HF tribander.
Features:
Compass Display - Stop may be set at North of South.
Gear System - Quiet, gear reduction braking system
Quick Disconnect Plug - For safety during lightning
Please Note!
All Yaesu rotators use an advanced locking (braking) mechanism & if you shake the body of the rotator you will be able to hear a slight rattle. This is perfectly normal. The design stops the rotator gears being damaged due to the inertia in the antenna when it comes to a stop.
Specifications |
G-450C Rotator |
Recommended Application | Light to Medium Duty. Perfect entry-level rotator |
Wind Load | 1 m² |
K-Factor (Turning Radius x Weight of Ae) | 100 |
Stationary Torque | 3,000kg/cm |
Rotation Torque | 600kg/cm |
Max Vertical Load | 100kg |
Max Vertical Intermittend Load | 300kg |
Backlash | 0.5º |
Mast Size | 32 - 63 Φ |
360º Rotation Time | 63sec @ 50Hz |
180º Elevation Time | N/A |
Boom Diametre | N/A |
Rotator Diametre x Height | 170 Φ x 263 |
Weight | 3.2kg |
Cable Requirement (# cores/wires) | 5 |
Specifications are subject to change |
