Icom IC-7300 Special Offer HF/6m/4m base transceiver

Today's Special Offer
Multiple Offers Available! See product description
Icom IC-7300 Special Offer HF/6m/4m base transceiver
Part Number: IC-7300
£1199.95 ( £999.96 EXC. VAT )
ESTIMATED SHIPPING COST:
Free
In Stock
Shipping to:
Add to cart
Call Now
Product Information
  • Overview
  • Resources
  • Customer Reviews


Selection of offers available!

FREE SM-30 Microphone OR FREE SP-38 Speaker OR Choose a PTRX7300 for only £99.95 (£90 OFF!)
OR 5 years warranty only £49.99! Add to basket at checkout to recieve 1 x discount.



FIRMWARE VERSION 1.41 NOW AVAILABLE - CLICK HERE TO DOWNLOAD

Would you like the PTRX fitted? Select the 'FIT PTRX7300 ON PURCHASE OF IC-7300' tick box for £20.00 labour time.


100 Watt - HF/50 & 50W on 70MHz SDR TRANSCEIVER with SSB / CW / RTTY / AM / FM

HRD CONNECTION INSTRUCTIONS

Update for Ordering RadioSport Headsets:

IC-7300 8-Pin Foster CS6-ICM 3.5mm Stereo Headphone Plug w/1/4" Adapter M360

HF/50/70MHz Transceiver

The IC-7300 is a revolutionary compact radio that will excite HF operators from beginners to experts. This new model has a high-performance real-time spectrum scope and employs a new RF direct sampling system. The IC-7300’s real-time spectrum scope provides top-level performance in resolution, sweep speed and dynamic range. While listening to received audio, the operator can check the real-time spectrum scope and quickly move to the intended signal. The combination of the real-time spectrum scope and waterfall function improves the quality and efficiency of HF operation.

The new RF direct sampling system employed by the IC-7300 realises class leading RMDR (Reciprocal Mixing Dynamic Range) and Phase Noise characteristics. In addition, the IC-7300 features the 70MHz band (European versions only), a large touch screen colour TFT LCD, convenient multi-function dial knob, automatic antenna tuner, voice recorder function and more.





Class Leading Real-Time Spectrum Scope
You no longer have to choose whether to listen to the audio or have the spectrum scope sweep for signals as the IC-7300’s real-time spectrum scope offers the simultaneous operations found in higher tier models. This means you can use either the spectrum scope or the waterfall to quickly move to an intended signal while listening to the receiver audio. The IC-7300’s touch screen introduces a “Magnify” function. So, when you first touch the scope screen around the intended signal, the touched part is magnified. A second touch of the scope screen changes the operating frequency and allows you to accurately tune.

High-Resolution Waterfall Function
The combination of the waterfall function and the real-time spectrum scope assists in maximum receive performance of the IC-7300 and increases QSO opportunities without missing weak signals. The waterfall function shows a change of signal strength over a period of time and allows you to find weak signals that may not be apparent on the spectrum scope.

Audio Scope Function
The audio scope function can be used to observe various AF characteristics such as microphone compressor level, filter width, notch filter width and keying waveform in the CW mode. Either the transmit or receive audio can be displayed on the FFT scope with the waterfall function and the oscilloscope.

RF Direct Sampling System
The IC-7300 employs an RF direct sampling system. RF signals are directly converted to digital data and processed in the FPGA (Field-Programmable Gate Array), making it possible to simplify the circuit construction. This system is a leading technology making an epoch in amateur radio.

New “IP+” Function
The new “IP+” function improves 3rd order intercept point (IP3) performance. When a weak signal is received adjacent to strong interference, the AD converter is optimized against signal distortion.

Class Leading RMDR (Reciprocal Mixing Dynamic Range) and Phase Noise Characteristics
The IC-7300’s RMDR is improved to about 97dB* (typical value) and Phase Noise characteristics are improved about 15dB (at 1 kHz frequency separation) compared to the IC-7200. The superior Phase Noise characteristics reduce noise components in both receive and transmit signals.
* At 1 kHz frequency separation (received frequency: 14.2MHz, MODE: CW, IF BW: 500Hz)

Large Touch Screen Colour TFT LCD
The large 4.3 inch colour TFT touch LCD offers intuitive operation. Using the software keypad of the touch screen, you can easily set various functions and edit memory contents.

Multi-Dial Knob for Smooth Operation
The combination of the multi-dial knob and the touch screen offers quick and smooth operation. When you push the multi-dial knob, menu items are shown on the right side of the display. You can select an item with a touch of the screen and adjust levels by turning the multi-dial knob.

SD Memory Card Slot for Saving Data
The IC-7300 can store various contents into SD card such as received and transmitted audio, voice memories, RTTY/CW memories, RTTY decode logs and captured screen images. Personal and firmware updating data can also be stored to the SD card for easy setting.

15 Discrete Band-Pass Filters
The IC-7300 has 15 discrete RF band-pass filters. The RF signal is only passed through one of the band-pass filters, while any out of range signals are rejected. High Q factor coils are used to minimize the loss in the RF band-pass filters.

Built-In Automatic Antenna Tuner
The antenna tuner memorizes its settings based on your transmit frequency, so that it can rapidly tune when you change operating bands. The Enforced Tuning function* allows a wide range of temporary antennas to be tuned.
* Do not use the Enforced Tuning function except in case of an emergency. Transmission power may be reduced.

Superior Sound Quality
To offer superior sound quality, a new speaker unit has been incorporated and is allocated dedicated space in the aluminium die-cast chassis.

Other features
• New HM-219 hand microphone supplied
• Effective large cooling fan system
• A Multi-function meter
• 101 memory channels (99 regular, 2 scan edges) • Optional RS-BA1 IP remote control software (the spectrum scope with the waterfall can be observed)
• CW functions: Full break-in, CW reverse, CW auto tuning

Specifications:

  • 70MHz band (European versions only)
  • Class Leading Real-Time Spectrum Scope
  • High-Resolution Waterfall Function
  • Audio Scope Function
  • RF Direct Sampling System
  • New “IP+” Function
  • Class Leading RMDR (Reciprocal Mixing Dynamic Range) and Phase Noise Characteristics
  • Large Touch Screen Colour TFT LCD
  • Multi-Dial Knob for Smooth Operation
  • SD Memory Card Slot for Saving Data
  • 15 Discrete Band-Pass Filters
  • Built-In Automatic Antenna Tuner
  • Superior Sound Quality
  • New HM-219 hand microphone supplied
  • Effective large cooling fan system
  • A Multi-function meter
  • 101 memory channels (99 regular, 2 scan edges)
  • Optional RS-BA1 IP remote control software (the spectrum scope with the waterfall can be observed)
  • CW functions: Full break-in, CW reverse, CW auto tuning

Accessories
  • AH-2B : Whip
  • AH-4 : Automatic Antenna Tuner
  • AH-5NV : NVIS Kit
  • AH-710 : Antenna
  • AH-740 : Automatic Tuning Antenna
  • CT-17 : Interface
  • HM-219 : Hand Microphone
  • MB-118 : Mobile Mounting Bracket
  • MB-123 : Carrying Handle
  • OPC-2321 : Control Cable Adapter
  • OPC-420 : Adapter Cable
  • OPC-599 : Cable
  • PS-126 : DC Power Supply
  • RC-28 : RC-28 IP Remote Control System
  • SM-30 : Desktop Microphone
  • SM-50 : Desktop Microphone
  • SP-23 : External Speaker
  • SP-33 : Base Station Speaker
  • SP-34 : Base Station Speaker with Filters
  • SP-35 : External Speaker
  • SP-35L : External Speaker
  • SP-38 : External Speaker



The "IC-7300 Resources Page"

Ian Wade, G3NRW, announces the introduction of the "IC-7300 Resources Page", available at:

www.g3nrw.net/IC-7300

The site contains hundreds of references to IC-7300 documentation, software, firmware, HOWTOs, TechNotes, reviews and other support material, plus a collection of over 80 (mostly) YouTube videos demonstrating many aspects of using the transceiver. Motivation for building the site arose from Ian's difficulties in finding all this information, much of which is scattered all over the internet. The site will particularly appeal to anyone who is considering buying the Icom IC-7300, as well as existing users who are continually looking for more information on this very popular transceiver.
(17 reviews)Write a review
What a radio....
George|03-12-2020
I am very impressed with the performance and quality of this animal. RX is really clear and looking forward to getting the SP-38 hooked up once back in stock. Very simple to set up and use. So far the internl tuner has managed to tune 1:1.0 my random length wire in to a 9:1 UNUN with ease. It is near resonant on all except 80m but not an issue and tunes up sweet. This radio does live up to all the hype and will not disappoint. Rating 11 out of 5 ;-)
Decent Radio But.....
Mark|17-11-2020
Decent radio, but I Icom neglected receiver and audio quality for bling. MY FT-891 has much better audio, filters and DSP on it is amazing. I got the PTRX-7300 panadapter and Airspy HF+ only because I already had the 7300 and the Airspy lying around but it greatly improved my experience with the 7300 and it's great having a proper sdr experience on a big screen using SDR console and Omnirig to sync the radio to the software. My advice to anyone thinking about buying a new 7300 + panadapter + SDR is don't, spend a little more on the Expert Electronics SUN SDR 2 DX, you get a proper SDR and great remote capabilities, regular updates and it's a proper SDR, the 7300 + Panadapter + SDR is very expensive. If you want a radio with buttons then buy the Kenwood TS-590SG, it's a much better radio and much better to use, better filters and audio + built in panadapter so you can add your own SDR which is the way all radios should be which gives People more options, a traditional radio with option to add sdr, I used the 590SG in a friends with SDR, its a much better radio to use. There's reports the 7300 overloads, it does not, keep the preamp off unless listening to 17m etc during the day or MW, it has an attenuator in the settings for MW which you need to turn off if you want to listen to MW but the sound quality is poor listening to LW/MW/SW because Icom cut off a lot of the lower frequencies and the EQ only makes it sound worse. It's a sensitive receiver so use the RF gain when you need to, I have to do this on all SDRs. The Good points about the 7300. Good TX Audio with stock Mic Easy to use. Built in Sound Card for Digital. Negatives Audio quality Filters NR not nearly as good as FT-891 Poor remote options, the RS-BA1 software is very poor Power Overshoot = bad for Amplifier.
Great SDR Transceiver with knobs!
Andrew|30-10-2020
My first new purchase for some years and wow!,how things have changed, had the panadapter option with bypass on filters so you can monitor all bands externally on my RSP1A, great radio!!
Superb on all fronts !
John|22-04-2020
Getting back into the hobby after a 10 yr hiatus...wanted an all-rounder and ML&S are the go-to dealers , even here in Scotland! Arrived next day, put up an end fed multiband and on the air in minutes, Americas, Asiatic Russia, Far East...no problem and great signal reports. ...opted for the rf output free accessory as I had an SDR-1 and wow! provides the full 27" monitor experience (7300 lacks a video-out) ...overall, highly impressed and I have only begun to scratch the surface of what this rig will do...Many Thanks ML&S and of course Icom ....a happy ham 73's de MM1ANP
Andy M0UKN
Andrew|25-12-2019
Bought the icom 7300 cant believe what I've been missing the receive is absolutely amazing and the dsp is out of this world would recommend this radio to anyone. Don't be put off by the menu it's a doddle to us took me 30mins. Thank you Martin lynch once again you have looked after me 100%. 73
Neil
Neil|25-05-2019
Great service from ML&S 10 out of 10 Folks and the 7300 is up there as well what a brilliant radio .Nice to have an internal ATU that works and the radio is so easy to use.
My first amateur radio
John|23-03-2019
After much deliberation I finally went for the 7300 and can’t recommend it enough. It has everything I need and more, built in ATU is great. The best feature is the spectrum scope, makes it easy to find signals on quiet bands. If your thinking about getting this radio do not hesitate, you will be pleased with the purchase.
A great transceiver
Uriah|01-11-2018
Easy to use. Has all the features I need and the service I got was fine. I also have a Yaesu FT-991 and I like the IC-7300 better
Superb SDR Transceiver
Nick|20-09-2018
As a long standing ML&S customer, I decided to purchase the IC-7300 and am not disappointed. Superb screen, great sensitivity and almost all the features radio hams need without buying all those extras. I recommend the Icom external speaker (although the internal one is pretty good), as it directs audio to the user.
I absolutely love 💕 my new Icom IC-7300
Wayne|24-03-2018
I have only had my new Icom IC-7300 for a couple of days and i absolutely love my new radio. This has to be the best full size transceiver i have ever owned, the receive is an absolute pleasure to listen to straight from the built in speaker. The touch screen makes operating the most used functions a breeze to adjust. Setting up was very easy, even more so after watching a few video’s on you tube. I operate mainly QRP and with my 7300 set to 10 watts i went to work, it wasn’t long before i got my very first contact.. Reports were excellent as i kind of expected from this quality transceiver. ML&S were on the ball with getting my new radio shipped out to me.. I ordered this radion on Wednsday afternoon and by 1PM the next day i had it in my hands. Very well packaged & super fast delivery, what else could you ask for. I very Highly recommend ML&S for a great & friendly service.. 73 de Wayne 2e0bvj
Mr
Stuart|11-10-2017
Had mine a year and just love it the best rig I have ever owned MLS are good dealers , good customer service.There is some quirky stuff with setting up on dig operating , but you can find loads of YT support . Worked loads of dx since owning her and phone and CW are a joy to operate . Recommended to new amateurs and more experienced operators
Icom IC-7300
Edwin|29-09-2017
I have had the Icom IC-7300 for just over a week now i am blown away by the quality of the reviver, so much bang for your buck. the transceiver is a joy to use.
M0KYW
Manuel|16-07-2017
Outstanding receiver! Superb filtering! Excellent audio both in transmission and receive! Good work, Icom!!! An enjoyable transceiver full of good features at a great price, and at Martin Lynch with 3 year warranty plus the optional SP-38 external speaker at half price, you just can`t ask for more! Highly recommended!
This really could be a keeper...........
Richard|15-11-2016
The more I use it the more it's becoming the rig of choice. My Pro3 is still my main base stn. but the features of my 7300 are keeping me interested, ok it's not a contesters radio, that aside it's incredible value for money and just enjoyable to use. Today I took my 7300 out portable onto the Akamas Peninsula and with the bright sunshine here in 5B4 land and compared it with a 991, oh dear, hopefully the new 991A has a better screen as the 7300 is far and away superior than the 991. The 7300 screen is vivid and clearer/sharper apart from being an all round easier touch screen radio to use. Of course the Icom has a much better receiver anyway but today was a test in harsh sunshine conditions......
Buy one!
Malcolm|11-10-2016
Had the IC-7300 since mid-July, 2016. Amazing piece of kit - the more I use it the more I like it! I operate CW, voice, and digital modes - it excels on them all.
IC7300 Win 7
Jeff|08-08-2016
A cautionary tale- I had this radio up and running on WSPR and it suddenly failed 'USB device not recognised' in Windows after a few days. I thought the 7300 USB interface had failed (just about to phone ML&S) but to be sure I rolled my WIN7 Professional back to its 27/07 checkpoint and it's now working properly again:-) Thank you Microsoft for sending out a bug....do they ever test anything properly? I doubt it.
IC7300
Jeff|01-08-2016
I have had this radio nearly 2 weeks now. Excellent build quality and a function rich radio. The rf gain / squelch fooled me for 10 mins as it was turned fully anti-clockwise as received, and it seemed the radio was deaf. Be aware this control behaves differently from a 'conventional' (non-SDR) radio. I now have it working well on WSPR having changed the CI-V Address to 76h as used by my IC7200 as the IC7300 isn't defined to WSPR-X (yet). I will now have to re-deploy my IC7200. This is an excellent value for money radio with a great (quiet) receiver...and once again great service from ML&S - delivered safely and on time:-)
