High-Quality Patch Cable (Ultraflex 10)

Overview

Patch Lead:

Select your desired cable length from the drop-down menu (5m, 10m, or 15m) to suit your specific setup needs.

For added convenience, customise your Patch Cable with your choice of connector fittings. Available options include 2 x PL-259 connectors or N-Type connectors. Please visit our product accessories page for more information and to add these fittings to your order.

Enhance your ham radio setup with our High-Quality Patch Cable, designed specifically for amateur radio enthusiasts. This superior cable features extraordinary flexibility, making it ideal for tight bends and rotor antennas. With far better performance than RG213, it boasts an additional foil layer for protection against electromagnetic interference and exceptional attenuation, ensuring minimal signal loss even at higher frequencies and long distances.

Key Features:

Attenuation: Excellent performance with low signal loss (e.g., 1.2 dB/100m at 7 MHz, 2.0 dB/100m at 28 MHz).
Power Handling: Capable of handling up to 12,000 Watts peak power.
Construction: High-pressure foamed polyethylene dielectric, UV-resistant black PVC jacket, and a triple-layer design.
Flexibility: Minimum bending radius of 80mm, perfect for tight installations.
Temperature Range: Operates reliably from -40°C to +60°C (-40°F to +140°F).

Whether you're setting up a new station or upgrading your existing equipment, our Patch Cable ensures robust and reliable connections.

Specifications:

Impedance: 50 Ohm ± 3
Screening Efficiency: >105 dB (100-2000 MHz)
Inner Conductor: 7x1.0mm copper wires
Jacket Diameter: 10.3 mm ± 0.15
Capacitance: 78 pF/m ± 2
Velocity Factor: 83%
UV Resistance: Yes

For optimal performance in amateur radio applications, trust the High-Quality Patch Cable. Order now and experience the difference in your radio communications.

Product Information

Patch Lead:

Select your desired cable length from the drop-down menu (5m, 10m, or 15m) to suit your specific setup needs.

For added convenience, customise your Patch Cable with your choice of connector fittings. Available options include 2 x PL-259 connectors or N-Type connectors. Please visit our product accessories page for more information and to add these fittings to your order.

Enhance your ham radio setup with our High-Quality Patch Cable, designed specifically for amateur radio enthusiasts. This superior cable features extraordinary flexibility, making it ideal for tight bends and rotor antennas. With far better performance than RG213, it boasts an additional foil layer for protection against electromagnetic interference and exceptional attenuation, ensuring minimal signal loss even at higher frequencies and long distances.

Key Features:

Attenuation: Excellent performance with low signal loss (e.g., 1.2 dB/100m at 7 MHz, 2.0 dB/100m at 28 MHz).
Power Handling: Capable of handling up to 12,000 Watts peak power.
Construction: High-pressure foamed polyethylene dielectric, UV-resistant black PVC jacket, and a triple-layer design.
Flexibility: Minimum bending radius of 80mm, perfect for tight installations.
Temperature Range: Operates reliably from -40°C to +60°C (-40°F to +140°F).

Whether you're setting up a new station or upgrading your existing equipment, our Patch Cable ensures robust and reliable connections.

Specifications:

Impedance: 50 Ohm ± 3
Screening Efficiency: >105 dB (100-2000 MHz)
Inner Conductor: 7x1.0mm copper wires
Jacket Diameter: 10.3 mm ± 0.15
Capacitance: 78 pF/m ± 2
Velocity Factor: 83%
UV Resistance: Yes

For optimal performance in amateur radio applications, trust the High-Quality Patch Cable. Order now and experience the difference in your radio communications.
