The Sierra Radio Systems SIR-472 is a slim DIN rail mounted 6A relay for use with Sierra Station Controller systems and other suitable low-voltage control installations.
It provides a compact way to add relay switching to a station control panel, remote site cabinet, repeater installation, or shack automation setup. The slim DIN rail format makes it well suited to tidy control-panel layouts where multiple relays or control modules need to be mounted in a limited amount of space.
The SIR-472 is a 12V single pole double throw relay with a maximum contact current of 6A. It also includes an LED indicator, making it easier to see relay state during installation, testing, and fault-finding.
Key Features
- Slim DIN rail mounted relay
- 12V relay operation
- Single pole double throw relay arrangement
- Maximum contact current of 6A
- Super slim form factor
- DIN rail mounting clip
- LED indicator
- Suitable for station automation and control panels
- Useful for remote stations, repeater sites, and shack control systems
- Ideal accessory for use with the SIR-321 GPIO module
- Helps add additional relay switching to a Sierra Station Controller installation
Typical Uses
- Adding relay switching to a Sierra Station Controller system
- Remote switching of compatible low-current circuits
- Control panel relay outputs
- Repeater site control systems
- Remote HF station switching
- Shack automation projects
- DIN rail mounted station control cabinets
- Interfacing the SIR-321 GPIO module with external equipment
- Switching auxiliary control lines where suitable for the relay rating
Station Controller System Role
The SIR-472 is normally used as a relay accessory within a Sierra Station Controller installation.
It is particularly suited for use with the SIR-321 General Purpose GPIO Module, where the GPIO module’s outputs can be used to operate external relays and controlled circuits. This allows the Station Controller dashboard or automation flow to control additional station equipment through a compact DIN rail relay.
Unlike Sierra DCN modules, the SIR-472 does not communicate directly over the Device Control Network. It is a relay accessory that must be wired into a suitable control circuit.
Power and Wiring Notes
The SIR-472 is a 12V relay and must be wired into a suitable control circuit.
It is not a standalone powered DCN module, and it is not supplied with a plug-in power supply. The controlling module, control wiring, power source, load wiring, and fuse protection must all be suitable for the intended installation.
Specifications
| Specification | Details |
|---|---|
| Brand | Sierra Radio Systems |
| Model | SIR-472 |
| Product type | Slim DIN rail relay |
| Relay voltage | 12V |
| Relay arrangement | Single pole double throw |
| Maximum contact current | 6A |
| Mounting style | DIN rail mounting clip |
| Indicator | LED indicator |
| Typical controller | SIR-321 General Purpose GPIO Module |
| Power requirement | Requires suitable 12V control wiring |
| DCN communication | No direct DCN communication |
Important Note
This listing is for the SIR-472 Slim DIN Rail 6A Relay only.
SIR-321 GPIO module, SIR-310 host adapter, installation kit, DCN hub, power supply, control wiring, fuses, load wiring, station equipment, and other accessories are not included unless stated otherwise.
Please ensure that the relay, wiring, control source, load, and fuse protection are suitable for the voltage and current being switched. The relay must not be used above its rated contact current.
