EAntenna 50LFA6XL (12,33 dBi ヨ 22,6 dB F/B) - R2010124
SKU Part Number: 17800.06-6XL
Boom length 7.30m, Max rotating radius 3.70m, Weight 12.65kg   The EAntenna LFA antennas for 50 MHz represent the largest development in antennas...
Read More
£459.00 £382.50
Availability: In stock
call

Seen this product cheaper elsewhere?

Call 0345 2300 599

Boom length 7.30m, Max rotating radius 3.70m, Weight 12.65kg



The EAntenna LFA antennas for 50 MHz represent the largest development in antennas with moderate boom length for a single performance.

This performance is characterized in that:

  • You can listen to very low signals without noise QRM and QRN alter audio clarity.
  • Direct feeding is 50 ohms, so there is no loss whatsoever regarding adaptation lines. (You can request an optional cable terminated with connector and soldered PL-UHF, N or BNC on the end if required)
  • The bandwidth covers the entire band with low SWR.
  • The radiation pattern is wide, so that the signal is not as selective as you rotate the antenna a minimum.
  • Its ratio of F/B is high, since only antenna boom lengths can get exaggerated.
  • The gain is comparable with other models of antennas always larger in dimensions.
Brand EAntenna
Wind Surface (m²) 0.3
Boom length / Gain 6 El / 730 cm / 18.1 dBi
Weight 12.65 kg
Supported Bands 6m
Number of Elements 6
Boom length [cm] 730 cm
Front/Back ratio [dB] 22.37
Balun Included No, not required
Max. Power [W] 5000 W
Band 6m
Frequency Range 50.0 - 50.5 MHz
Polarisation Horizontal
Rotation Radius [m] 3.7
Antenna Guying Yes
Antenna Type Directional Antenna
Design of antenna Yagi
Strut no
Antenna mount Center Mount
Max. Windspeed (km/h) 160
Gain [dBi] ( (above ground) 18.14
Gain [dBi] (free space) 12.33
