The Armoloq TPA Package for Wouxun KG-1000G and KG-UV950P is a protective mounting platform designed to give your radio a tougher, more practical installation setup while still allowing full access to the radio’s controls.
The TPA is a two-piece protective mounting platform that secures to the radio’s four side mounting holes. Its wrap-around design helps protect both the radio body and control head, making it a useful upgrade for mobile, portable, field, and fixed installations where additional protection and secure mounting are required.
This package also includes the RF PnP Package PL-TNC/STRT3, providing a convenient RF relocation setup with a PL-259 to TNC lead, TNC bulkhead connector, adaptor, and relocation mounting hardware.
Key Features
- Protective mounting platform for Wouxun KG-1000G and KG-UV950P
- Two-piece wrap-around design
- Helps protect the radio body and control head
- Secures to the radio’s four side mounting holes
- Allows access to radio controls
- Made from 5052 aluminium
- 3.2mm (1/8in) material thickness
- Matte black powder-coated finish
- Includes correct-length M4 mounting screws for use with the TPA frame
- Includes RF PnP Package PL-TNC/STRT3
- Suitable for mobile, portable, and fixed radio installations
Compatible Radios
| Brand | Compatible Models |
|---|---|
| Wouxun | KG-1000G |
| Wouxun | KG-UV950P |
Package Includes
Base TPA Package
- 1 x TPA-KG1000 protective mounting platform
- 4 x M4-0.7 x 10mm mounting screws
RF PnP Package PL-TNC/STRT3
- 1 x PL-259 straight to TNC male lead, terminated to RG58C/U, 0.3m (1ft)
- 1 x TNC bulkhead female connector
- 1 x TNC male to BNC female adaptor
- 1 x Relocation mount with hardware
Construction
| Specification | Details |
| Material | 5052 aluminium |
| Material thickness | 3.2mm (1/8in) |
| Finish | Matte black powder coat |
| Design | Two-piece protective mounting platform |
| Mounting method | Secures to the radio’s four side mounting holes |
Dimensions
| Measurement | Metric | Imperial |
| Length | 266.7mm | 10.500in |
| Length with MBS-1280 | 377.8mm | 14.875in |
| Depth | 63.5mm | 2.500in |
| Weight, TPA only | 0.34kg | 0.750lb |
Typical Uses
- Mobile radio installations
- Portable field radio setups
- Vehicle-mounted Wouxun radios
- Shack installations needing extra protection
- Relocating RF connections for cleaner cable routing
- Protecting the radio body and control head during use
Important Notes
The supplied M4-0.7 x 10mm screws are the correct length for attaching the TPA to the radio. They should not be used without the TPA pack frame.
This package is designed for the Wouxun KG-1000G and Wouxun KG-UV950P. Please check your radio model before ordering.
Important Note
This listing is for the Armoloq TPA Package with RF Package PL-TNC/STRT3 only. Radio, antenna, power supply, coaxial cable beyond the included RF lead, and other accessories are not included unless stated otherwise.
