Yaesu FTDX10
100W HF/50/70MHz Hybrid SDR Transceiver
Exceptional receiver performance in a compact desktop transceiver. The FTDX10 combines Yaesu's acclaimed narrow-band SDR architecture, advanced digital signal processing and real-time spectrum visualisation for demanding DX, contest and everyday amateur-radio operation.
FREE Yaesu SP-30 Speaker
Purchase a Yaesu FTDX10 from Martin Lynch & Sons and receive the matching SP-30 external speaker completely free, while promotional stocks last.
The SP-30 is an additional ML&S promotional accessory and is not supplied as standard by Yaesu. Offer subject to stock availability.
Discover the Yaesu FTDX10
Take a closer look at the FTDX10 in this video.
Serious receiver performance. A more compact station.
The Yaesu FTDX10 brings much of the advanced receiver technology developed for the flagship FTDX101 series into a more compact 100W transceiver. At its heart is Yaesu's Hybrid SDR configuration, which combines a high-performance narrow-band receiver with direct-sampling technology for the real-time spectrum display.
The result is an HF radio designed to perform well under demanding conditions. Its roofing filters, low-noise oscillator and extensive IF DSP controls help separate wanted signals from interference, while the touchscreen spectrum display provides an immediate picture of band activity.
With a built-in automatic antenna tuner, 100W transmit capability and USB connectivity, the FTDX10 suits traditional voice and CW operators as well as enthusiasts using computer-based digital modes.
Built for demanding HF operation
HF and VHF Output
Adjustable RF output up to 100W on supported operating modes across HF, 50MHz and the UK 70MHz allocation.
SDR Architecture
A narrow-band SDR receiving path works alongside direct-sampling SDR technology for spectrum visualisation.
Colour Touchscreen
High-visibility touchscreen incorporating a real-time spectrum scope, waterfall and 3DSS display modes.
Automatic Antenna Tuner
Fast internal antenna matching with 100-channel tuning memory, reducing the need for an external tuner with suitable antenna systems.
Two complementary SDR technologies
Like the FTDX101 series, the FTDX10 uses Yaesu's Hybrid SDR approach. A conventional down-conversion receiver with narrow roofing filters is combined with a direct-sampling SDR system, allowing the radio to prioritise receiver performance without losing the benefits of a detailed spectrum display.
Narrow-Band SDR Receiver
A 9MHz first intermediate-frequency architecture provides the opportunity to use narrow crystal roofing filters ahead of the receiver's digital processing stages. The filters help attenuate unwanted strong signals before they reach the analogue-to-digital converter.
Direct-Sampling SDR Scope
Direct-sampling technology provides the real-time spectrum and waterfall displays. Signals can be identified visually and selected for reception through the radio's narrow-band receiving system.
This arrangement is particularly useful during contests, DX pile-ups and operation near powerful local signals, where both close-in selectivity and an awareness of band activity are important.
Outstanding close-in dynamic range
The FTDX10 uses a 250MHz High Resolution Direct Digital Synthesizer (HRDDS), carefully selected receiver components and high-performance crystal roofing filters to achieve strong receiver performance with closely spaced signals.
Reciprocal Mixing Dynamic Range at 2kHz separation.
Blocking Dynamic Range at 2kHz separation.
Third-order Intermodulation Dynamic Range at 2kHz separation.
Yaesu-published receiver figures measured in the 14MHz band at 2kHz separation under specified test conditions.
Crystal roofing filters for crowded bands
The FTDX10 has three factory-installed crystal roofing filters, providing 500Hz, 3kHz and 12kHz bandwidths. These filters help reduce unwanted energy reaching the receiver's subsequent processing stages.
| Filter Bandwidth | Configuration |
|---|---|
| 500Hz CW | Factory-fitted |
| 3kHz SSB | Factory-fitted |
| 12kHz AM | Factory-fitted |
| 300Hz CW | Optional XF-130CN |
For dedicated CW operators, the optional Yaesu XF-130CN 300Hz roofing filter provides additional narrow-band selectivity. The optional filter is not included as standard.
Take control of interference
Beyond the front-end roofing filters, Yaesu provides a comprehensive collection of digital signal-processing tools for improving intelligibility and controlling interference.
IF SHIFT and WIDTH
Adjust the position and bandwidth of the receive passband to reduce interference from nearby stations.
IF Notch and DNF
Suppress unwanted carriers and persistent interference using manual and digital notch-filter functions.
Digital Noise Reduction
DNR processing provides adjustable noise reduction to improve listening comfort under suitable conditions.
CONTOUR Filtering
Shape the receive audio response to emphasise or attenuate selected frequency components.
See and explore the band
The 5-inch colour TFT touchscreen incorporates Yaesu's 3DSS (3-Dimensional Spectrum Stream) system, providing a visual representation of changing signal activity alongside conventional spectrum and waterfall displays.
3DSS Display
Observe changes in signal strength across the selected frequency span using three-dimensional spectrum visualisation.
Direct Frequency Entry
Touch the frequency display to access the numeric keypad or select signals directly from the scope display.
Flexible Spectrum Modes
Centre, fixed and cursor operating modes provide different ways of displaying and navigating the band.
The Multi-Purpose VFO Outer Dial provides direct control of functions including the clarifier, memory-channel recall and custom-select operations without relying entirely on touchscreen menus.
100W output and integrated antenna matching
The FTDX10 provides adjustable transmit power up to 100W across supported HF, 50MHz and UK 70MHz amateur bands. Its transmitter uses a push-pull MOSFET final amplifier, an aluminium heatsink and an 80mm low-noise cooling fan.
A high-speed automatic antenna tuner is fitted as standard, with a 100-channel memory system for recalling previous matching settings. The tuner is intended to match antennas within its specified impedance range and should not be considered a substitute for an appropriate antenna system.
Transmit facilities include RF and AF monitoring, a three-stage parametric microphone equaliser for SSB and AM, Quick Memory Bank and band-stack functions.
Digital modes and remote operation
USB connectivity supports integration with compatible computer software for CAT control and digital-mode operation. Correct USB driver installation and software configuration may be required depending on the computer and operating system.
The optional Yaesu SCU-LAN10 network remote-control system allows compatible remote operation over a LAN or internet connection. It supports radio control and spectrum-monitoring functions using the associated software. The SCU-LAN10 is not included with the standard FTDX10.
Compact construction and station power
Measuring approximately 266 x 91 x 263mm and weighing around 5.9kg, the FTDX10 provides substantial base-station capabilities without requiring the desk space of a larger flagship transceiver.
The FTDX10 operates from a regulated 13.8V DC supply and draws approximately 23A at full 100W output. A suitable power supply with adequate continuous-current capacity is required and is not included in the standard package. Allow adequate ventilation around the rear cooling system.
What's included?
The SP-30 is supplied under the separate ML&S promotional offer. The optional XF-130CN roofing filter, SCU-LAN10 remote-control unit and 13.8V power supply are not included as standard.
Official Yaesu Documentation
Refer to the official FTDX10 operating manual for complete technical specifications, installation guidance and operating instructions.
View Yaesu FTDX10 InformationYaesu FTDX10
100W HF/50/70MHz Hybrid SDR Transceiver, 5-inch colour touchscreen, built-in automatic antenna tuner and high-performance narrow-band SDR receiver.
General Specifications
| Model | FTDX10 |
|---|---|
| Manufacturer | Yaesu Musen |
| Transceiver Type | HF/50MHz Hybrid SDR, UK 70MHz configuration |
| Receiver | Single narrow-band SDR receiver with direct-sampling SDR scope |
| Receive Coverage | 30kHz to 75MHz (operating range) |
| Transmit Coverage | 1.8 to 54MHz amateur bands, plus 70 to 70.5MHz UK amateur allocation |
| Emission Modes | CW, AM, LSB, USB, FM, RTTY, PSK |
| Frequency Stability | ±0.5ppm, after 1 minute |
| Antenna Impedance | 50 ohms nominal, tuner off |
| Supply Voltage | 13.8V DC ±15%, negative ground |
| Receive Current | Approximately 2.5A with no signal, 3A with signal |
| Transmit Current | Approximately 23A at 100W |
| Operating Temperature | 0 to +50 degrees C |
| Dimensions | 266 x 91 x 263mm (W x H x D, excluding projections) |
| Weight | Approximately 5.9kg (transceiver only) |
Transmitter Specifications
| RF Output | 5 to 100W, supported non-AM modes |
|---|---|
| AM Carrier Output | 5 to 25W |
| SSB Modulation | Balanced |
| AM Modulation | Low-level |
| FM Modulation | Variable reactance |
| FM Deviation | ±5kHz / ±2.5kHz narrow |
| Microphone Impedance | 600 ohms nominal |
| Carrier Suppression | 60dB or better |
| Unwanted Sideband Suppression | 60dB or better |
Receiver Architecture and Performance
| Architecture | Hybrid SDR: narrow-band down-conversion receiver and direct-sampling SDR spectrum display |
|---|---|
| First IF | 9MHz architecture |
| Local Oscillator | 250MHz HRDDS |
| RF Filtering | 15 separate band-pass filters |
| RMDR at 2kHz | 116dB or greater |
| BDR at 2kHz | 141dB or greater |
| Third-Order IMDR at 2kHz | 109dB or greater |
| Local Oscillator Phase Noise | Approximately -145dBc/Hz at 2kHz separation, manufacturer figure |
| IF DSP | IF SHIFT, WIDTH, NOTCH, DNF, DNR and CONTOUR |
| Roofing Filters | 500Hz, 3kHz and 12kHz standard |
Crystal Roofing Filters
| Bandwidth | Status |
|---|---|
| 500Hz CW | Standard |
| 3kHz SSB | Standard |
| 12kHz AM | Standard |
| 300Hz CW | Optional XF-130CN |
Display, Tuner and Controls
| Display | 5-inch colour TFT touchscreen |
|---|---|
| Spectrum | 3DSS, waterfall and conventional spectrum scope |
| Spectrum Modes | Centre, fixed and cursor |
| Tuning Controls | MAIN VFO and MPVD multifunction outer dial |
| Automatic Antenna Tuner | Built in, 100-channel memory |
| ATU HF Impedance Range | 16.7 to 150 ohms |
| ATU 50MHz Impedance Range | 25 to 100 ohms |
| Computer Interface | USB CAT/audio connectivity |
| Remote Operation | Optional SCU-LAN10 network remote-control system |
Construction and Cooling
| Final Amplifier | Push-pull MOSFET design |
|---|---|
| Power Devices | RD70HUP2 MOSFET |
| Cooling | Aluminium heatsink and 80mm axial-flow fan |
| Power Connection | External regulated 13.8V DC power supply |
Supplied Equipment
| Transceiver | Yaesu FTDX10 |
|---|---|
| Microphone | SSM-75E hand microphone |
| Power Lead | DC power cable |
| Documentation | Manufacturer operating documentation |
| Power Supply | Not included |
Additional ML&S Promotional Accessory
Free Yaesu SP-30 matching external loudspeaker, worth £89.95, supplied with qualifying FTDX10 purchases while promotional stocks last. This is separate from the manufacturer's standard package.
Installation and Configuration Notes
Power supply: Use a suitable regulated 13.8V DC supply with adequate continuous-current capacity for the 23A maximum transmitting requirement.
70MHz: The UK destination specification includes 70 to 70.5MHz operation. Confirm the supplied radio's configuration and comply with the appropriate amateur-radio licence conditions.
Antenna tuner: The built-in tuner operates within specified impedance limits. Antennas outside those limits may require a suitable external matching arrangement.
Optional upgrades: The XF-130CN roofing filter and SCU-LAN10 network remote-control equipment are separate accessories.
Yaesu Operating Manual
Consult the manufacturer's operating manual for complete installation instructions, operating procedures and technical specifications.
