High-Sensitivity 66 Channel GPS Receiver
-
1200/9600bps APRS® Data Communication
-
Fully Supports WiRES-X Operation
-
Wide-range Receiver Coverage: From 108MHz to 550MHz on both MAIN/SUB bands
-
Bluetooth® Hands-free Operation: Available with the optional BU-5 board
-
Flexible Angle Adjustment of the Control-Head: By attaching the optional SJMK-500 Swing-Head Kit
-
Control-Head with Microphone Jack: In addition to the microphone connections on the front of the main unit
Yaesu FTM-310DE - 144/430MHz 55W/50W C4FM Digital/ FM Mobile Transceiver w/ ASP
SKU Part Number:
FTM-310DE
FTM-310DE Series - True Dual Band Transceiver
The FTM-310DE series offers true dual-band operation with independent receivers for different bands or...
Read More
Read More
Special Price
£339.00
Regular Price
£459.00
Availability: In stock

Seen this product cheaper elsewhere?
Call 0345 2300 599FTM-310DE Series - True Dual Band Transceiver
The FTM-310DE series offers true dual-band operation with independent receivers for different bands or within the same band, including C4FM/C4FM simultaneous receive (V/U, V/V, U/V, U/U). It provides 55W on VHF and 50W on UHF (with selectable power options: 55W/50W, 25W, 5W).
Key Features:
-
Heavy Duty Heat Sink with FACC (Funnel Air Convection Conductor): Ensures stable and reliable transmit power.
-
6W Total Audio Output: Powered by AESS (Acoustic Enhanced Speaker System), which combines a 3W front speaker inside the control head and a 3W main-unit speaker. The AESS system provides clear, high-fidelity audio even in noisy environments.
-
Full Dot-Matrix Display: Delivers clear, precise information for efficient operation.
Remarkable Functions:
-
C4FM Digital Mode: C4FM delivers excellent audio quality with a low Bit Error Rate (BER) compared to GMSK digital. The original YAESU error correction technology ensures reliable communication.
-
Super-DX + ASP (Audio Digital Signal Processor):
-
Super-DX: Activates a high sensitivity RF amplifier for both C4FM and FM analog modes.
-
ASP: Enhances the FM analog mode with selectable Auto/Manual modes. The ASP AUTO mode automatically detects weak signals, while ASP MANUAL allows users to switch on/off manually.
-
-
PMG (Primary Memory Group): Assign up to 5 VFO or Memory Channel frequencies to the PMG for simultaneous monitoring with two receivers. The reception status is displayed in real-time on the PMG screen with a bar graph.
-
AUTO Mode: Monitors all PMG channels, with up to two channels heard simultaneously.
-
MANUAL Mode: Monitors a single channel, with other channels displayed on screen.
-
-
MAG (Memory Auto Grouping): Automatically groups and recalls memory channels for each band. User can also customize memory channels in My Group (M-GRP).
-
CFL (Customized Function List): Register up to 9 frequently used functions from the 127 menus for easy access.
Advanced Display Features:
-
High-resolution Band Scope: The dual receive and scope operation display is switchable. With the left DIAL knob, the frequency range can be centered, and the signal at the center marker is received. The right DIAL knob allows the marker to move across the display to receive signals at different frequencies.
FM Friendly Digital using AMS (Automatic Mode Select):
-
AMS: Automatically detects whether the receiving signal is C4FM Digital or FM analog and adjusts the receiver mode accordingly.
-
DG-ID (Digital Group ID): Communicate only with group members who share the same frequency and DG-ID number.
-
GM (Group Monitor): Monitors stations with the same DG-ID number within range.
Additional Features:
-
High-Sensitivity 66 Channel GPS Receiver
-
1200/9600bps APRS® Data Communication
-
WiRES-X Operation Supported
-
Wide-range Receiver Coverage: From 108MHz to 550MHz on both MAIN/SUB bands.
-
Bluetooth® Hands-free Operation: Available with the optional BU-5 board.
-
Flexible Control-Head Adjustment: With the optional SJMK-500 Swing-Head Kit, allowing better positioning of the control-head.
Some fundamental and remarkable features of the FTM-310DE series are:
C4FM Digital Mode:
In both C4FM digital and FM analog modes, the sensitivity of the RF amplifier can be increased by activating the Super-DX function. When operating in FM analog mode, the ASP can be activated in addition to the Super-DX. ASP AUTO/ MANUAL modes are selectable. In ASP AUTO mode, Super-DX is always turned on and ASP automatically activates when the transceiver detects weak signals in FM analog mode. In ASP MANUAL mode, Super-DX and ASP can be manually switched on and off each time [S-DX] key is briefly pressed.
*Super-DX is available with the FTM-310DR without the SPU-1 board.
** The main-unit speaker will not sound when the ASP function is in use but 3W front speaker positioned inside the front head ensures clear and powerful audio.
PMG (Primary Memory Group):
Up to 5 VFO or Memory Channel frequencies can be assigned to the PMG and monitored using two different receivers. The reception status of the PMG channels is displayed in real time with a bar graph on the PMG screen. AUTO or MANUAL mode is selectable. AUTO mode monitors all PMG channels and up to two channels can be simultaneously heard. Transmit is automatically moved to the received channel. MANUAL mode always monitors the manually selected channel and transmit also stays on that channel. The signal received on the other channel is also shown on the screen and the audio can be heard.
MAG (Memory Auto Grouping):
Memory channels can be automatically grouped and recalled for each band. In “My Group(M-GRP)”, any memory channels can be registered according to the user’s preference regardless of band.
CFL (Customized Function List):
Up to 9 frequently used functions from the 127 Menus can be registered and then easily selected.
High-resolution Band Scope:
Dual receive and Scope operation display is switchable each time the [BAND](SCOPE) key is pressed and held. Up to 47 channels can be displayed with the Scope operation. By rotating the left DIAL knob, the frequency range can be centered and the signal at the center marker is received. By rotating the right DIAL knob, the marker can be moved across the display and the signal at the market is received. Transmission can be performed at the frequency of the marker position at any time.
FM Friendly Digital using AMS(Automatic Mode Select):
AMS (Automatic Mode Select) automatically determines whether the receiving signal is C4FM Digital or FM analog and sets the receiver to the appropriate mode.
DG-ID (Digital Group ID) and GM (Group Monitor):
DG-ID function allows using two-digit ID numbers (00 - 99) to communicate only with specific group members who set the same frequency and DG-ID number in advance. GM (Group Monitor) function can be utilized to automatically monitor when group member stations with the same DG-ID number are operating within communication range.
Some other practical features of the FTM-310DE series are:
