main product photo
Grazioli G-Max Collinear 5/8 Over 1/4 Wave 27 to 28.5MHz Vertical Antenna
SKU Part Number: GRAZ-8010030
The Grazioli G-Max is a high-performance collinear vertical antenna designed for serious 10m and 11m operation. Tunable from 27 to 28.5MHz, it uses a...
Read More
Finance from £8.51 a month
£319.96
Pre Order
call

Seen this product cheaper elsewhere?

Call 0345 2300 599

The Grazioli G-Max is a high-performance collinear vertical antenna designed for serious 10m and 11m operation. Tunable from 27 to 28.5MHz, it uses a 5/8 wave over 1/4 wave in-phase collinear configuration to provide high gain, a compressed main lobe and a low radiation angle for excellent long-distance performance.

Built on the proven mechanical design of Grazioli’s FE10V, the G-Max is designed to offer performance comparable to, or better than, some small directional antennas, while retaining the practical advantage of omnidirectional coverage. This makes it an excellent choice for operators who want strong DX performance without needing a rotator or beam antenna system.

The antenna is constructed from cold-drawn AW6063-T66 aluminium alloy tubing, chosen for its strength, precision and long-term reliability. The tube sections are manufactured with accurate diameters and wall thicknesses, giving a secure fit with minimal play. All hardware is AISI-304 and AISI-316 stainless steel for excellent outdoor durability.

The ground plane uses four full quarter-wave radials, each 2.7m long, made from sturdy telescopic aluminium sections. The radials are fixed with U-bolts and self-locking nuts, with fibreglass reinforcements supplied to strengthen the joints and prevent tube crushing.

The G-Max uses a carefully positioned high Q coil between the central radiating sections. This provides phase delay between the 1/4 wave and 5/8 wave sections, compensates for capacitive reactance and transfers RF power efficiently to the upper section. The antenna is DC grounded, helping to reduce static build-up and atmospheric noise.

A custom Grazioli 50 ohm UHF female connector is fitted, with PTFE insulation and a 24K gold-plated centre pin for long-term reliability. The antenna is also supplied with a 3-point fifth wheel bracing system, which is strongly recommended for installation.

Key Features

  • High-performance collinear vertical antenna
  • 5/8 wave over 1/4 wave in-phase design
  • Tunable from 27 to 28.5MHz
  • Suitable for 10m and 11m operation
  • Omnidirectional radiation pattern
  • High gain, 3.5dBd or 5.65dBi
  • Low radiation angle for improved DX performance
  • Maximum power handling of 5kW continuous, all modes
  • Four full quarter-wave 2.7m radials
  • High Q phasing and matching coil
  • DC grounded design to help reduce static and impulse noise
  • Cold-drawn AW6063-T66 aluminium alloy construction
  • AISI-304 and AISI-316 stainless steel hardware
  • Custom 50 ohm UHF female connector
  • PTFE insulation and gold-plated centre pin
  • Supplied with 3-point fifth wheel bracing system
  • Rugged G-Max stainless steel mounting bracket

Construction Details

The G-Max is built from precision AW6063-T66 aluminium alloy tubing, with fibreglass, brass and PTFE components used throughout the antenna system. The custom Grazioli connector uses a nickel-plated CW614N brass body, a 24K gold-plated centre pin and PTFE insulation, protected by a special elastomer cap to help prevent water and humidity ingress.

Installation Notes

Due to its height and performance-focused design, the G-Max should be installed on a suitable support mast with clear space around the antenna and radials. The supplied 3-point fifth wheel bracing system should be used for additional stability. As with all high-power vertical antennas, careful mechanical installation, weatherproofing and good quality coaxial cable are important for best long-term performance.
