The new Xiegu G7250 looks set to be a fantastic radio, and we expect it to be in very high demand.
We are now accepting pre-orders. Place your deposit today to secure your position in the queue for the first batch arriving from the factory.
We do not yet have a confirmed price or delivery date. We will update this page with further information as soon as it becomes available.
The new Xiegu G7250 is a split-type 100 W HF and 50 MHz SDR transceiver, featuring a separate controller and RF deck. Built around a direct RF-sampling architecture, it is designed for radio operators who want flexible installation, touchscreen and physical controls, digital signal-processing tools and a built-in automatic antenna tuner.
G7250 Key Features
- RF direct-sampling architecture for excellent performance
- Covers the HF and 50 MHz amateur radio bands
- Built-in adjustable digital filters
- Digital noise reduction, Noise Blanker and Noise Threshold functions
- Built-in voice recorder and playback for calling
- Preset CW Morse code message calling
- Spectrum scope and waterfall display
- Built-in automatic antenna tuner
- Remote baseband signal transmission over a network
Separate Controller and RF Deck
The Xiegu G7250 combines a separate display and control head with a main radio unit. The two sections can be installed independently, giving operators greater flexibility when arranging a station or adapting the radio to different operating environments.
The transceiver uses a direct RF-sampling platform with dedicated baseband and RF units. It covers 0.5-30 MHz and 50-54 MHz, supports SSB, CW, NFM, AM and DIG modes, and provides up to 100 W output on HF and 90 W on 50 MHz, both specified at ±1 dB.
7-inch Touchscreen and Physical Controls
The detachable control head features a 17.8 cm high-resolution capacitive touchscreen together with a full set of physical controls. Operators can use the touchscreen, buttons or a combination of both.
A spectrum scope and waterfall display provide a clear visual view of activity across the selected frequency range.
Signal Processing and Operating Tools
The G7250 includes adjustable digital filters, digital noise reduction, a noise blanker and a noise-threshold function. Voice recording and playback can be used for calling, while preset CW messages support repeated Morse code calls.
The published feature list also includes remote baseband signal transmission over a network.
The receiver front end uses multi-stage filtering and high-Q inductors to reduce input loss and support signal selectivity. A two-stage, large-dynamic-range preamplifier is specified to improve front-end dynamic range and IP3 performance.
Published receiver figures include 0.2 µV sensitivity for SSB, CW and FM, 2 µV for AM, and an MDS of -138 dBm.
Automatic Antenna Tuner with Band Memory
A built-in automatic antenna tuner compensates for antenna mismatch across a stated impedance range of 20-150 Ω.
The tuner stores settings for each band and reloads them when the operator returns to a previously tuned band. Initial tuning is specified at no more than 10 seconds, while memory tuning is specified at no more than 0.1 seconds.
Xiegu G7250 Specifications
| Frequency range | 0.5-30 MHz; 50-54 MHz |
|---|---|
| Operating modes | SSB, CW, NFM, AM, DIG |
| Minimum frequency step | 1 Hz |
| External power supply | 9.0-15.0 V DC |
| Transmit power | HF: 100 W ±1 dB; 50 MHz: 90 W ±1 dB |
| Receive sensitivity | 0.2 µV (SSB/CW/FM); 2 µV (AM) |
| MDS | -138 dBm |
| Operating temperature | 0-55 °C |
| Spurious suppression | ≥55 dB |
| Carrier suppression | ≥40 dB |
| Sideband suppression | ≥50 dB |
| SSB frequency response | 300-2700 Hz (-6 dB) |
| FM deviation | ±5 kHz |
| Microphone impedance | 200 Ω-10 kΩ |
| Tuner matching range | 20-150 Ω |
| Initial tuning time | ≤10 seconds |
| Memory tuning time | ≤0.1 seconds |
| Supported accessory | GY-10 external speaker |
Product information and specifications are preliminary and may be changed by the manufacturer without notice.
The new Xiegu G7250 is a split-type, separate controller and RF deck, 100 W HF and 50 MHz SDR transceiver built around a direct RF-sampling architecture. It is aimed at radio operators who want flexible installation, touchscreen and physical controls, digital signal-processing tools and a built-in automatic antenna tuner. Read on for a concise look at the features and specifications.
G7250 Key Features
- RF Direct Sampling architecture for excellent performance
- Covers HF and 50 MHz amateur radio bands
- Built-in adjustable digital filters
- Digital noise reduction, Noise Blanker (NB), and Noise Threshold (NTH)
- Built-in voice recorder and playback for calling
- Pre-set CW (Morse code) message calling
- Spectrum and waterfall display
- Built-in automatic antenna tuner
- Remote baseband signal transmission over a network
The Xiegu G7250 combines a separate display and control head with a main radio unit. The two parts can be deployed independently, giving operators more flexibility when arranging a station or adapting the radio to different operating environments.
The transceiver uses a direct RF-sampling platform with dedicated baseband and RF units. It covers 0.5-30 MHz and 50-54 MHz, supports SSB, CW, NFM, AM and DIG modes, and provides up to 100 W output on HF and 90 W on 50 MHz, both specified at ±1 dB.
7-inch touchscreen and physical controls
The detachable control head features a 17.8 cm high-resolution capacitive touchscreen together with full physical controls. Operators can use touch input, buttons or a combination of both. A spectrum scope and waterfall display provide a visual view of activity across the selected frequency range.
Signal processing and operating tools
The G7250 includes adjustable digital filters, digital noise reduction, a noise blanker and a noise-threshold function. Voice recording and playback can be used for calling, while preset CW messages support repeated Morse code calls. The published feature list also includes remote baseband-signal transmission over a network.
The receiver front end uses multi-stage filtering and high-Q inductors to reduce input loss and support signal selectivity. A two-stage, large-dynamic-range preamplifier is specified to improve front-end dynamic range and IP3 performance. Published receiver figures include 0.2 µV sensitivity for SSB, CW and FM, 2 µV for AM, and an MDS of -138 dBm.
Automatic antenna tuner with band memory
A built-in automatic antenna tuner compensates for antenna mismatch across a stated impedance range of 20-150 Ω. The tuner stores settings for each band and reloads them when the operator returns to a previously tuned band. Initial tuning is specified at no more than 10 seconds, while memory tuning is specified at no more than 0.1 seconds.
Xiegu G7250 specifications
| Frequency range | 0.5-30 MHz; 50-54 MHz |
|---|---|
| Operating modes | SSB, CW, NFM, AM, DIG |
| Minimum frequency step | 1 Hz |
| External power supply | 9.0-15.0 V DC |
| Transmit power | HF: 100 W ±1 dB; 50 MHz: 90 W ±1 dB |
| Receive sensitivity | 0.2 µV (SSB/CW/FM); 2 µV (AM) |
| MDS | -138 dBm |
| Operating temperature | 0-55 °C |
| Spurious suppression | ≥55 dB |
| Carrier suppression | ≥40 dB |
| Sideband suppression | ≥50 dB |
| SSB frequency response | 300-2700 Hz (-6 dB) |
| FM deviation | ±5 kHz |
| Microphone impedance | 200 Ω-10 kΩ |
| Tuner matching range | 20-150 Ω |
| Initial tuning time | ≤10 seconds |
| Memory tuning time | ≤0.1 seconds |
| Supported accessory | GY-10 external speaker |
Specifications are subject to change.
