Buy your Yaesu FTX-1 Field new from us at full price and you are eligible for £255 cashback directly from Yaesu, subject to their terms.
Offer ends 31 December 2026
Cashback Details & Claim →You pay the full product price to ML&S; cashback is claimed separately from Yaesu after purchase. Eligibility and claim deadlines are subject to Yaesu's terms.
Yaesu FTX-1 Field
10W HF/50/70/144/430MHz All-Mode SDR Transceiver
Advanced SDR performance, genuine dual-band reception and C4FM digital voice in a compact portable transceiver. With an included 6,400mAh lithium-ion battery and up to 10W output using external DC power, the FTX-1 Field brings an impressive range of station capabilities wherever you operate.
FREE SCF-1 + SPG-1
Receive both a Yaesu SCF-1 cooling fan and an SPG-1 protection guard completely free with your FTX-1 Field. Combined value £58.95.
While promotional stocks last. The SCF-1 uses the rear battery mounting position when fitted.
Serious radio performance. Wherever you operate.
The Yaesu FTX-1 Field combines HF, 50MHz, 70MHz, 144MHz and 430MHz amateur-band operation in a compact SDR transceiver. Designed for operators who want to take a capable station away from the shack, it brings SSB, CW, AM, FM and C4FM digital voice into one portable package.
Whether you enjoy Summits on the Air, Parks on the Air, portable DX, field days or operating from the garden, the FTX-1 provides sophisticated digital signal processing, a 4.3-inch colour touchscreen, wide receive coverage and the flexibility to operate from its supplied battery or an external DC supply.
The Field is the portable-only version of the FTX-1 series. The more powerful FTX-1 Optima uses the same Field Head but adds the SPA-1 RF amplifier for high-power base-station use.
Two ways to power your station
Standalone Battery Operation
Fit the included SBR-52LI 6,400mAh lithium-ion battery to the rear of the radio for cable-free operation. Output is adjustable up to 6W, with a separate 5W QRP setting.
External 13.8V DC Operation
Connect a suitable external DC power supply for up to 10W on supported bands. The UK 70MHz configuration is limited to lower power, as specified by Yaesu. External DC also enables charging of the fitted battery.
Yaesu quotes up to approximately nine hours on HF SSB and eight hours on VHF/UHF FM under its specified 6-6-48 duty-cycle test conditions. Real operating time will vary with transmit power, receiving activity, screen settings and battery condition.
High-performance reception in a portable package
The FTX-1 uses high-resolution analogue-to-digital conversion and FPGA-based processing, drawing on technology developed for Yaesu's FTDX10. Its receiver combines direct sampling below 48MHz with IF sampling at higher frequencies, providing wide coverage from shortwave to UHF.
Carefully engineered RF front-end filtering, a high-purity 110.592MHz sampling clock and fast 32-bit DSP processing contribute to clear reception and effective management of interference.
SHIFT and WIDTH
Adjust the position and width of the receiver passband to reduce nearby interference.
NOTCH and CONTOUR
Reduce interfering carriers and shape the received audio response.
DNR and Noise Blanker
Digital noise reduction and impulse-noise suppression for more comfortable listening.
CW Audio Peak Filter
APF functionality helps emphasise CW signals during narrow-band reception.
Monitor two frequencies simultaneously
Unlike many compact portable transceivers, the FTX-1 Field supports true dual-band reception. Listen to HF and VHF, HF and UHF, or two VHF/UHF frequencies at the same time, including simultaneous C4FM digital reception on supported combinations.
HF/V, HF/U, V/U, U/V, V/V and U/U. Simultaneous HF/HF reception is not supported.
This makes the FTX-1 particularly useful when operating HF while monitoring a local repeater, coordinating portable activity or following digital voice channels.
4.3-inch touchscreen and 3DSS spectrum display
The FTX-1 Field is fitted with a high-resolution colour TFT touchscreen. Yaesu's three-dimensional spectrum stream display shows changes in signal activity, while the physical VFO and FUNC controls retain the tactile operating experience expected from a dedicated amateur transceiver.
3DSS Spectrum Scope
View signals, spectrum activity and frequency changes at a glance.
Memory Channel Scope
Monitor the receiving status of up to 43 stored channels using a bar-graph view.
Operating Indicators
Dedicated MAIN/SUB and VFO mode indicators provide useful operating feedback.
From CW and SSB to C4FM and FT8
C4FM Digital Voice
Yaesu System Fusion digital voice with AMS to select between compatible FM and C4FM transmissions automatically.
FT8 Preset
Convenient preset settings to simplify integration with popular computer-based digital operating software.
MAG, QMB and PMG
Organise memory channels by band, save operating configurations and monitor priority VHF/UHF channels.
CW Functions
Built-in keyer, CW zero-in, auto zero-in, reverse, memory keyer and supported break-in operation.
APRS Data
Supports APRS data communication, with a compatible optional GPS unit required for location functionality.
Super-DX
Selectable receive processing intended to improve reception of weak signals on supported analogue modes.
Stay powered wherever you operate
The supplied SBR-52LI battery attaches directly to the rear of the Field Head. Its 6,400mAh capacity provides standalone operation without an external battery or power cable.
Charging is supported using a suitable USB Type-C Power Delivery charger, with Yaesu specifying a charger rated at 45W or greater and the appropriate 15V output. The Field Head can also charge the fitted battery when connected to a suitable external 13.8V DC supply.
Need a compatible charger?
A mains USB-C PD charger is required for USB charging and is not included as part of the standard Field package. Check the charger's supported output profiles before use.
View USB-C PD Charger →Portable antenna options and external tuners
The FTX-1 Field does not contain a built-in automatic antenna tuner. When operating with antennas that require impedance matching, Yaesu offers the optional FC-80 clip-on automatic tuner and FC-90 external long-wire tuner, both designed for suitable Field Head operation.
Other compatible antenna arrangements include the ATAS-120A active tuning antenna and ATAS-25 manually tuned portable antenna, subject to the correct connection and power requirements. The ATAS-120A requires external 13.8V DC power for compatible operation.
Our FTX-1 setup guide explains how to configure the radio for the Yaesu ATAS-120A antenna.
Read the ATAS-120A Setup Guide →Want 100W? Discover the FTX-1 Optima.
The FTX-1 Field uses the same core transceiver as the Optima. The Optima adds the SPA-1 power amplifier, allowing up to 100W HF/50MHz and 50W VHF/UHF operation with an external DC supply, plus an integrated HF/50MHz antenna tuner.
View the Yaesu FTX-1 Optima →What's included?
The SCF-1 and SPG-1 are additional ML&S promotional accessories, subject to stock. The SPA-1 amplifier, external 13.8V power supply, USB-C PD mains charger and optional antenna tuners are not included.
Yaesu FTX-1 Documentation
Explore the manufacturer's brochure, operating instructions and official information for the FTX-1 series.
Yaesu FTX-1 Field
Portable all-mode SDR transceiver covering HF, 50MHz, 70MHz, 144MHz and 430MHz, with integrated battery operation and a 4.3-inch colour touchscreen.
General Specifications
| Model | FTX-1 Field |
|---|---|
| Manufacturer | Yaesu Musen |
| Type | Portable all-mode SDR transceiver |
| TX Frequency | Amateur bands from 1.8MHz to 430MHz; UK 70.0-70.5MHz subject to configuration |
| RX Frequency | 30kHz-174MHz and 400-470MHz |
| Operating Modes | SSB, CW, AM, FM, C4FM and supported data modes |
| Frequency Stability | ±0.5ppm under specified conditions |
| Antenna Impedance | 50 ohms nominal |
| Operating Temperature | -10 to +50 degrees C |
| Dimensions | 213 x 89 x 55mm (W x H x D) |
| Weight | Approximately 1.25kg, manufacturer figure |
Transmitter and Power
| Battery Output | 0.5-6W |
|---|---|
| External DC Output | 0.5-10W, subject to band and mode |
| UK 70MHz, External DC | Up to 6W |
| AM Carrier, Battery | 0.5-2.5W |
| AM Carrier, External DC | 0.5-2.5W |
| Battery | SBR-52LI, 6,400mAh lithium-ion |
| Battery Supply | 10.8V nominal |
| External Power | 13.8V DC ±15% |
| RX Current, No Signal | Approximately 0.6A |
| RX Current, Signal | Approximately 0.9A |
| TX Current, 6W | Approximately 2.5A |
| TX Current, 10W | Approximately 3A |
Receiver and DSP
| Architecture Below 48MHz | Direct-sampling SDR |
|---|---|
| Architecture Above 48MHz | Single-conversion IF sampling |
| Sampling Clock | 110.592MHz oscillator |
| DSP | 32-bit high-speed DSP |
| DSP Functions | SHIFT, WIDTH, NOTCH, CONTOUR, APF, DNR, NB |
| Dual Receive Combinations | HF/V, HF/U, V/U, U/V, V/V, U/U |
| HF/HF Simultaneous RX | Not supported |
| C4FM Dual Receive | Supported on applicable VHF/UHF combinations |
| Built-in Antenna Tuner | No; compatible external tuners available |
Display and Operating Functions
| Display | 4.3-inch TFT colour touchscreen |
|---|---|
| Spectrum Scope | 3DSS spectrum display |
| Memory Channel Scope | Displays up to 43 channels |
| Memory Functions | MAG, QMB, PMG |
| Digital Voice | C4FM, AMS |
| Digital Data | FT8 preset, APRS and compatible data communication |
| Computer Connectivity | USB CAT, audio and transmit control |
| Memory Storage | microSD card slot |
| Audio | Two front-facing speakers |
Battery and Charging
| Supplied Battery | Yaesu SBR-52LI |
|---|---|
| Capacity | 6,400mAh |
| Chemistry | Lithium-ion |
| HF SSB Runtime | Up to approximately 9 hours, Yaesu 6-6-48 test cycle |
| VHF/UHF FM Runtime | Up to approximately 8 hours, Yaesu 6-6-48 test cycle |
| USB-C Charging | Compatible USB-C PD charger, 45W or greater and suitable 15V output profile |
| External DC Charging | Supported with fitted battery and suitable 13.8V supply |
Standard Package Contents
| Transceiver | FTX-1 Field Head |
|---|---|
| Battery | SBR-52LI 6,400mAh |
| Microphone | SSM-75E |
| Power Cable | 2-pin round-connector DC power cable |
| SPA-1 Amplifier | Not included |
| Mains Power Supply | Not included |
| Automatic Antenna Tuner | Not included |
Additional ML&S Promotional Equipment
SCF-1: Cooling fan, worth £29.95.
SPG-1: Protection guard, worth £29.00.
Both supplied free with qualifying FTX-1 Field purchases while promotional stocks last. These are additional retailer-offer accessories rather than standard factory package contents.
Installation and Compatibility Notes
External power: The radio supports a suitable regulated 13.8V DC supply, drawing approximately 3A at its specified 10W output.
UK 70MHz: Operation depends on the destination configuration. Maximum output on 70MHz is lower than the general 10W external-power rating.
SCF-1: The cooling fan occupies the rear position normally used by the SBR-52LI battery. These items cannot be mounted together in that position.
Portable tuning: Optional FC-80 and FC-90 antenna tuners are available for compatible Field Head installations.
Power upgrade: The separately purchased SPA-1 amplifier allows the Field Head to be converted into the higher-power Optima configuration.
