Used Icom IC-R9500 Professional Communications Receiver
A true Icom flagship and one of the finest wideband communications receivers ever produced!
The Icom IC-R9500 is a professional-grade communications receiver covering an incredible 5kHz to 3335MHz, offering exceptional performance across HF, VHF, UHF and beyond.
Originally selling for nearly £13,000, this remarkable receiver combines outstanding sensitivity, superb selectivity and some serious signal analysis capabilities. With a 109dB dynamic range, five independent roofing filters and dual 32-bit DSP processors, the IC-R9500 was designed for those who demand the very best in receiver performance.
The large 7-inch colour TFT display provides a detailed spectrum scope, whilst the built-in digital voice recorder, adjustable IF filters and ultra-stable OCXO reference make this an incredibly capable piece of equipment.
Key Features:
-
Wideband coverage from 0.005 to 3335MHz
-
USB, LSB, CW, AM, FM, WFM and FSK reception
-
109dB dynamic range and +40dBm IP3 on HF
-
Five independent roofing filters
-
Dual 32-bit floating-point DSP processors
-
Large 7-inch colour TFT display
-
High-resolution spectrum scope with wideband monitoring
-
Ultra-stable OCXO with ±0.05ppm frequency stability
-
1,220 memory channels
-
Built-in digital voice recorder
-
Digital IF filtering, twin PBT and noise reduction
-
External monitor connection via VGA
Our Used Example
This particular IC-R9500 is in very nice condition, having spent its life in a private shack. A fantastic opportunity to own one of Icom's most impressive receivers at a fraction of its original selling price.
These receivers are becoming increasingly difficult to find, particularly in such lovely condition. If you've always fancied owning an IC-R9500, this is certainly one worth considering!
SPECIFICATIONS
| GENERAL | |
| Type: | HF/VHF/UHF receiver/scanner |
| Frequency range: | 0.005-3335 MHz (Cellular blocked in the US) |
| Tuning steps: | Down to 1 Hz |
| Frequency stability: | Less than 0.05 ppm (after 5 min warmup) @ 0-50°C (32-122°F) |
| Mode: | AM / AM-Sync / FM / WFM / SSB / CW / FSK (APCO P25 DV option) Also analog TV (AM video), but not in the US version |
| Channels / memory management: | 1000 regular 100 auto write 100 scan skip 20 scan edge Non-volatile EEPROM storage |
| Power supply: | Mains: 100 / 120 / 230 / 240 VAC (3-pin IEC C14 connector) |
| Current drain / power consumption: | Less than 100 VA |
| Antenna impedance / connector: | 0.005-30 MHz: 50 ohm / SO-239 0.005-30 MHz: 500 ohm / Phono (RCA) 30-1150 MHz: 50 ohm / N-jack 1150-3300 MHz: 50 ohm / N-jack |
| Dimensions (W*H*D): | 424*149*340 mm (16.69*5.87*13.39") |
| Weight: | 20 Kg (44 lb) |
| Other features: | Dual DSP. 7" TFT. +40 dBm IP3. Spectrum scope. Two channel NB. VSC. AFC. Five roofing filters. DVR. Video in/out. CI-V/RS-232C. CTCSS/PL and DTCS. RTTY decoder (45 and 50 baud). |
| RECEIVER SECTION | |
| Receiver system: | Quadruple conversion superheterodyne 1st IF: ? MHz 2nd IF: ? KHz |
| Sensitivity: | AM (10 dB S/N) 0.1-1.8 MHz: 6.3 uV 1.8-30 MHz: 1 uV 30-3335 MHz: 1.4 uV FM (12 dB SINAD) 1.8-30 MHz: 0.5 uV 30-3335 MHz: 0.5 uV WFM (12 dB SINAD) 30-3335 MHz: 1.4 uV SSB/CW/FSK (10 dB S/N) 0.1-1.8 MHz: 0.5 uV 1.8-30 MHz: 0.16 uV 30-3335 MHz: 0.32 uV |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | AM (BW=6 KHz) >6 KHz (-3 dB) <15 KHz (-60 dB) FM (BW=15 KHz) >12 KHz (-6 dB) <20 KHz (-60 dB) WFM (BW=350 Hz) >150 KHz (-6 dB) SSB/FSK (BW=2.4 KHz) >2.4 KHz (-3 dB) <3.6 KHz (-60 dB) CW (BW=500 Hz) >500 Hz (-3 dB) <700 Hz (-60 dB) |
| Image rejection: | 0.1-30 MHz: >70 dB 30-3335 MHz: >50 dB |
| AF output power / speaker: | 2.6 W at 10% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm), 8 ohm |
