Call 0345 2300 599The product is in good condition, including power supply and connection cable. No box or manual.
SPECIFICATIONS
| GENERAL | |
| Type: | HF/VHF receiver/scanner |
| Frequency range: | 0.009-50 MHz |
| Tuning steps: | Down to 1 Hz |
| Frequency stability: | 2.5 ppm @ 0 to 50°C (32 to 122°F) |
| Mode: | AM / AMS / FMN / SSB / CW / FSK + UDM (User defined mode) DRM option |
| Channels / memory management: | Depending on software |
| Power supply: | 11-13 VDC (Barrel connector) |
| Current drain / power consumption: | 500 mA |
| Antenna impedance / connector: | 50 ohm / SMA |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
| Other features: | USB 2.0. +31 dBm IP3. Attenuator. Spectrum analyzer. MW filter. Waterfall. 16-bit 100 MSPS A/D conversion. Three parallel demodulator channels. |
| RECEIVER SECTION | |
| Receiver system: | Direct-sampling, digital down-converting SDR |
| Sensitivity: | AM (10 dB S+N/N) 2 uV @ 10 MHz FM (12 dB SINAD, 3 KHz deviation, 12 KHz BW) 0.56 uV @ 10 MHz SSB (10 dB S+N/N, 2.1 KHz BW) 0.35 uV @ 10 MHz |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | 10 Hz to 62.5 KHz (Variable in 1 Hz steps) |
| Image rejection: | 90 dB |
| AF output power / speaker: | PC software demodulation |
