Grazioli MV6 40m Upgrade Kit
SKU Part Number:
GRAZ-805001U
The Grazioli MV6 40m Upgrade Kit allows existing MV6 owners to add 40m band coverage to their antenna system. Designed as a dedicated extension kit,...
Read More
Read More
£209.95
Availability: In stock
Seen this product cheaper elsewhere?
Call 0345 2300 599
The Grazioli MV6 40m Upgrade Kit allows existing MV6 owners to add 40m band coverage to their antenna system. Designed as a dedicated extension kit, it adds the necessary coil, capacitive hat, vertical whip section and DBFC wire counterpoise to make the MV6 resonant and properly adapted for 7MHz operation.
Once fitted, the kit converts the MV6 into a 40m plus 20m central whip arrangement, while retaining the existing higher band performance of the MV6. This makes the antenna functionally equivalent to the newer Grazioli MV7, which includes 40m coverage as standard.
The kit uses a 40m coil assembly with capacitive hat radials, plus Grazioli’s DBFC, Dual Band Folded Counterpoise, system. The DBFC wire counterpoise is installed onto the existing MV6 radial system and helps the 40m band operate correctly without requiring a completely new antenna installation.
Supplied with the required hardware and installation components, the MV6 40m Upgrade Kit is a practical way to expand an existing MV6 installation for improved low band capability.
Key Features
- Dedicated 40m extension kit for the Grazioli MV6
- Adds 40m, 7MHz, coverage to an existing MV6 antenna
- Converts the MV6 into an equivalent configuration to the Grazioli MV7
- Includes 40m coil assembly with capacitive hat
- Includes vertical whip extension components
- Includes DBFC, Dual Band Folded Counterpoise, system
- Designed to install onto the existing MV6 radial system
- Maximum input power of 1500W SSB
- Supplied with the required installation hardware
- Installation manual included
Supplied Components Include
- 40m coil assembly
- Capacitive hat radial set
- Aluminium whip extension tubes
- DBFC wire counterpoise
- Inductor assembly
- Wire insulators
- Stainless steel hardware
- Clamps, caps and fixing components
- MV6 upgrade kit installation manual
Specifications
- Product: Grazioli MV6 40m Upgrade Kit
- Application: 40m extension kit for Grazioli MV6
- Added band coverage: 40m, 7MHz
- Maximum input power: 1500W SSB
- Parts weight: 0.75kg
- Package weight: 1.9kg
- System type: Coil, capacitive hat and DBFC wire counterpoise
Installation Notes
The kit is designed for quick and straightforward installation when following the supplied manual. The DBFC wire counterpoise should be fitted to the existing radial system as described in the instructions. As with any antenna modification, final tuning and SWR should be checked with a suitable antenna analyser before use.
