REZ Antenna Systems 4-Band Scout Linked Dipole Kit

Skip to the beginning of the images gallery

SKU Part Number: REZ-LDK

The REZ Antenna Systems 4-Band Scout Linked Dipole Kit, REZ-LDK, is a DIY antenna kit designed for use with the REZ Scout Base. It allows operators...
Read More

£65.95

Pre Order

Seen this product cheaper elsewhere?

Call 0345 2300 599

Overview

The REZ Antenna Systems 4-Band Scout Linked Dipole Kit, REZ-LDK, is a DIY antenna kit designed for use with the REZ Scout Base. It allows operators to build a custom 4-band linked inverted V dipole, making it ideal for POTA, SOTA, Field Day and other portable HF operations.

The kit supports up to 4 bands, with frequencies as low as 7MHz. The wire elements are not pre-cut, giving you the flexibility to choose the bands you want to build the dipole for. This makes it a good option for operators who want a tailored portable antenna rather than a fixed pre-configured setup.

The kit includes 23.5m (77ft) of 18 gauge tinned copper wire with a durable silicone jacket, designed to remain flexible even in cold conditions. Genuine Anderson Powerpole connectors are used for the band links, allowing secure and reliable connections when changing bands in the field.

With included wire winders, shrink tubing, plastic clips, ring terminals and element insulators, the REZ-LDK gives you the main components required to build and fine-tune a reliable portable linked dipole for the Scout system.

Key Features

DIY 4-band linked inverted V dipole kit
Designed for use with the REZ Scout Base
Supports up to 4 user-selected bands
Can be built for frequencies as low as 7MHz
Ideal for POTA, SOTA, Field Day and portable HF operation
Elements are not pre-cut, allowing custom band selection
Includes 18 gauge tinned copper wire with silicone jacket
Wire remains flexible in cold conditions
Genuine Anderson Powerpole connectors for reliable band links
Includes wire winders for transport and storage
Supplied with hardware and tuning instructions

What Is Included

23.5m (77ft) of 18 gauge tinned copper wire
12 x Anderson Powerpole connectors
2 x 9.5mm (3/8 inch) marine-grade shrink tubes
2 x 3.2mm (1/8 inch) shrink tubes
4 x plastic S clips
2 x 9.5mm (3/8 inch) ring terminals
6 x element insulators
2 x wire winders

Tools Required, Not Included

Wire cutters or strippers
Anderson Powerpole crimping tool
Heat gun or other suitable heat source for shrink tubing

Specifications

SKU: REZ-LDK
Product type: DIY linked dipole antenna kit
Antenna type: Multi-band linked inverted V dipole
Band coverage: User-built, typically 40m to 10m
Minimum supported frequency: 7MHz
Power rating: 200W PEP
Wire gauge: 18 gauge
Feedline connection: Not included
Antenna tuner requirement: Antenna and installation dependent

Important Note

This kit requires the REZ Scout Base to build the intended linked dipole configuration. The wire is supplied uncut, so measuring, cutting, assembly and tuning are required.
